• 5-axis CNC Machine
• 20,000 rpm HSK 63 spindle with CTS
• Low cutting hours 2800 hours
• 45-50 tool holders included
• Fully loaded options

Important: All machinery specifications must be independently verified by buyer. All machinery sales are subject to prior sale. Any agreement to purchase or sell machinery must be in writing.

• P-B0109* CELOS with Heidenhain TNC 640 includes 21.5″ ERGOline Touch® Control with Multi-Touch- Screen
• P-K0775 Economic Processing Package, consisting of:
• P-K0220* Infrared measuring probe Type Renishaw PP60 optical (OMP 60)
• P-K0224 3D quickSET Tool kit for control and compensation of the cinematic accuracy of 4 / 5 axis machine configurations
• P-H0152 ATC (Application Tuning Cycle) programmable feed parameter selection for machining task: accuracy/ surface/ speed
• P-K0706 Economic Production Package (AM / AS), consisting of:
• P-K0398 Production package:
• Scraper flight conveyor with coolant unit 600 l/160 gallon, paper band filter Discharge height: 950 mm / 37.4 in Width: 670 mm / 26.4 in. Internal coolant supply 40 bar/23 l/min / 580 psi / 6 gallon/min through spindle centre (AD)
• P-G0026 Cooling by air blast through spindle centre, selection with M function
• P-K0255 Rotating clear-view window
• P-K0365 Coolant ring jetfor vertical headstock, 16 water jets, 7 air jets
• P-G0085 Oil and emulsion mist separator Mechanical filter. Throughput volume 1,100 m3/h
• P-K0686 Tool measuring in machining area Blum Laser DIGILOG. Tool length and diameter measurement vertically
• P-K0816* Increased accuracy
• P-H0143 Electronic handwheel
• P-L0056 Safety package for power failure: Voltage control with fast deceleration trigger
• Controlled shut down of the control Display of last executed program number
