2020 HAAS ST-20Y CNC Lathe + Bar Feeder

Meet your technology and equipment needs with fair prices on great quality used CNC machines.

$0.00

Category CNC Lathes
Brand HAAS
Mfg Date and Year 01/2020

Category: CNC Lathes

Make an Offer Activate Pricing Metric Conversion

Chuck Size8.3" Hydraulic chuck Max Part Swing8.3" Max Cutting Diameter (with BMT65 turret)11.75" Max Cutting Length (varies with workholding)21" Bar Capacity2.5" X-AXIS TRAVEL8.4" Y-AXIS TRAVEL+/- 2" Z-AXIS TRAVEL22.5" Spindle NoseA2-6 Max Rating20 HP Max Speed4000 rpm Spindle bore3.5" C-axis positioning+/- 0.01 ° Number of Tools on turret12 stations Live tooling max. Speed4000 rpm HAAS Bar feeder specifications: Bar Diameter Range0.375" to 3.125" Bar Length Capacity48" Minimum Bar Length10" Max Weight of Total Bars650 lbs

8 Inch Hydraulic Chuck
4000-rpm Live Tooling with C axis, 12-Station BMT65 Turret
BMT65 Driven Toolholder Kit (1 90 degree + 1 straight)
BMT65 Standard Toolholder Kit
Rigid Tapping
High-Pressure Coolant
Automatic Tool Presetter
Belt-Type Lift up Chip Conveyor
Enclosure Exhaust System
High-Intensity Lighting
Parts Catcher
Programmable Hydraulic Tailstock
Remote Jog Handle with Touchscreen Display
Internal High-Voltage Isolated Transformer
Chip Tray Filter Kit

Important: All machinery specifications must be independently verified by buyer. All machinery sales are subject to prior sale. Any agreement to purchase or sell machinery must be in writing.
